Product features

• ▪ 7 inch color touch screen;

• ▪ Support multi language, convenient for different users;

• ▪ Built in environment automatic detection program, automatically detect the test environment and remind users;

• ▪ RS232 interface, optional PC control software operation.

Product parameters

• Product model


  Output waveform


  output voltage


  Output voltage polarity


  Output impedance


  Number setting


  Interval time


  Working power supply

• WT 255L


  1.2us/50us


  0.5~20 kV (customizable)


  Positive, negative, positive before negative, negative before positive


  500Q


  1~9999 times


  3~9999s


  AC220V，50/60Hz

Product recommendation

Impulse current generator sur 6ka

Model：SUR 6KA

The lightning surge generator sur 6ka is used to inspect the anti surge protection devices such as zinc oxide arrester valve piece, varistor, SPD, TVs tube, gas discharge tube, etc. for surge impact test. The product produces 8/20us surge pulse waveform, and the technical indicators of the waveform comply with the provisions of national standards and IEC standards.

Learn more

Impulse current generator sur 20KA

Model：SUR 20KA

The lightning surge generator sur 20KA is used to inspect the anti surge protection devices such as zinc oxide arrester valve piece, varistor, SPD, TVs tube, gas discharge tube, etc. for surge impact test. The product produces 8/20us surge pulse waveform, and the technical indicators of the waveform comply with the provisions of national standards and IEC standards.

Learn more

Single phase 20kV lightning surge generator sur S20

Model：SUR S20

Sur S20 lightning surge generator (maximum output voltage up to 20kV) complies with IEC (International Electrotechnical Commission) standards iec61000-4-5, ul1449, European electrical standard (en61000-4-5) and national standard (gb/t17626.5), large screen LCD touch screen control, program-controlled high voltage principle, peak voltage up to 20kV, suitable for outdoor products, military standard products and non-standard products.

Learn more
